Powerlink Cable - MK2 - Black - Female to Female - 0.15 m
Powerlink Cable - MK2 - Black - Female to Female - 0.15 m
Availability for pickup could not be loaded.
B&O powerlink cable for Neo products with DIN 8 pin
Power link cable in black with a length of 0.15 meters with DIN 8 pin female connectors at both ends. The cable is of Mk2 type.
Powerlink cable is used to connect B&O systems primarily with speakers.
Data on cable
- The cable is 0.15 meters long.
- DIN 8 pin male connector at both ends
- The cable has 8 internal wires with a shield around it. See more below.
- The color is black.
Read details about the cable here
Technical details about DIN 8 powerlink cable
Powerlink cable contains 8 wires, of which 2 pairs are twisted pair and shielded (right and left channel, 1 wire is shielded (data traffic) and one wire for Overload signal. The entire cable is shielded in one.
The cable is typically used for speakers with a display. These are B&O speakers such as BeoLab 3000, BeoLab 4500, BeoLab 5000, Penta MK II, and Penta MK III.
'The cable is also used for amplifiers, such as ML/MCL Converter and BeoLink Passive.'
The above speakers and amplifiers must use specific wires in the cable. Pin 6 on the connector is a Data pin, which is required to use the display on the speaker. Pin 1 on the connector is the power on/off for the speaker, and finally, pin 8 is overload detection on the amplifiers.
