Neo 7 Spacer for Beovision 7

Neo 7 Spacer brings your new TV all the way forward to the front edge - like before. Align the front edge of the TV and the Beolab 7 speaker so it looks like Beovision 7.

How Neo 7 Spacer works

The older B&O TV on the Beovision 7 stand aligned with the front edge of the Beolab 7 speaker. Newer TVs are not as deep as the old Beovision 7 TV, so the front edge of the TV does not align with the front edge of the speaker. That’s a matter of taste.

How to choose the right Neo Spacer for your TV on a Beovision 7 stand

If you want it as before, then Neo 7 Spacer is the answer. Now the front edge of the TV aligns with the front edge of the Beolab 7 speaker.

At the same time, you get a cavity behind the TV where cables, Apple TV, and other TV boxes can be hidden. You get a neat setup without cable clutter.

If you want to be sure your TV stands upright, use Neo Tilt Stop, read here

https://shop.neomesteren.dk/products/neo-7-tilt-stop-beovision-7-40

What are the measurements of the Spacer and how does it fit the Beovision 7 stand

• This Spacer is designed for a TV with VESA 300 x 200


• VESA measurement of 300 mm in width


• VESA measurement of 200 mm in height


• The depth is 100 mm. It moves the TV’s front 100 mm forward


• The product fits on a Beovision 7 stand


• There are both 6 mm thread thickness spacers and 8 mm (Samsung) threaded rods in the box


• Note - the spacers have a thread length of 10 mm (M6) and 12 mm length (M8). Check that the VESA holes on your TV are not so deep that you have a problem with the thread length.


• Threaded rods with longer threads can be supplied on request. Some Samsung TVs have holes set deep in the cabinet.

How do I choose the right Neo 7 Spacer

VESA is a standard for mounting TVs - but that’s where the standardization ends. Typically, VESA is specified as 300 x 200 or 300 x 300. These are the measurements between the holes on the back of the TV where the bracket is attached. The measurements are in millimeters, so VESA 300 x 200 means there are 300 mm between the holes (e.g., width) and 200 mm (e.g., height).

But the VESA standard does not specify where the holes are located on the TV. They can be very low (if the TV has electronics at the bottom) or they can be high.

You can get help here to find the right VESA plate

https://neomesteren.dk/saadan-vaelger-du-den-rigtige-vesa-plade

The VESA measurements determine which Spacer you need. You should consider how far forward the front of your TV should be. All TVs have different thicknesses, so our products vary in distance/depth. You should therefore expect the product to come as close to the front edge of the Beolab 7 speaker as possible.

What's included in the package for Neo 7 Spacer

Includes spacers, cover plate, and mounting screws for the VESA plate.
